Model Number | HI-3K-SH | HI-3.6K-SH | HI-4K-SH | HI-5K -SH | HI-6K-SH |
PV String Input Data |
|
|
|
|
|
Max. DC input power | 7000W | 7000W | 9000W | 9000W | 9000W |
Max. DC input voltage |
|
| 550V |
|
|
Operation voltage range |
|
| 80V-550V |
|
|
MPPT working voltage range |
|
| 90V-550V |
|
|
Number of independent MPPT/strings per MPPT |
|
| 2/1+1 |
|
|
MPPT max. current |
|
| 15A/15A |
|
|
Start-up voltage/Min.operating voltage |
|
| 100V/80V |
|
|
AC Output/Input Data (On-grid) |
|
|
|
|
|
Nominal output apparent power | 3000W | 3600W | 4000W | 5000W | 6000W |
Max. output apparent power | 3300VA | 4000VA | 4400VA | 5500VA | 6600VA |
Nominal output voltage |
|
| 230V/180V-280V |
|
|
Nominal ouput freqency |
|
| 50Hz,60Hz/±5Hz |
|
|
Rated output current | 13A | 15.6A | 18A | 22A | 26A |
Max. output current | 14A | 17A | 19A | 24A | 29A |
Power factor |
|
| -0.8~+0.8(adjustable) |
|
|
THDi |
|
| <3%(Nominal Output) |
|
|
Grid system pattern |
|
| L+N+PE |
|
|
Max.apparent power from utility grid | 6000VA | 7200VA | 8000VA | 10000VA | 12000VA |
Max.AC current from utility grid | 28A | 32A | 38A | 48A | 58A |
Back-up Output Data (UPS) |
|
|
|
|
|
Peak output apparent power | 4000VA,10s | 4600VA,10s | 5000VA,10s | 6000VA,10s | 7000VA,10s |
Nominal output apparent power | 3000VA | 3600VA | 4000VA | 5000VA | 6000VA |
Nominal output voltage |
|
| 208V,220V,230V,240V |
|
|
Nominal ouput frequency |
|
| 50Hz/60Hz |
|
|
Output THDV |
|
| <3% |
|
|
Automatic switch time |
|
| <10ms |
|
|
Battery Input Data |
|
|
|
|
|
Battery type |
|
| Li-Ion |
|
|
Nominal battery voltage |
|
| 300V |
|
|
Battery voltage range |
|
| 85V-450V |
|
|
Max. charging voltage |
|
| 450V(Confifigurable) |
|
|
Max. charging/discharging current | 30A | 30A | 30A | 30A | 30A |
Battery capacity(AH) |
|
| 50-2000 |
|
|
Charging strategy for Li-Ion battery |
|
| Self-adaption to BMS |
|
|
Eciency |
|
|
|
|
|
Max. effificiency | 98% | 98% | 98% | 98% | 98% |
Europe effificiency | 97 . 5% | 97 . 5% | 97 . 5% | 97 . 5% | 97 . 5% |
Max. battery to load effificiency | 97% | 97% | 97% | 97% | 97% |
Protection |
|
|
|
|
|
Anti islanding protection |
|
| Yes |
|
|
Insulation impedance protection |
|
| Yes |
|
|
RCD detection |
|
| Yes |
|
|
PV reverse polarity protection |
|
| Yes |
|
|
Output over voltage protection |
|
| Yes |
|
|
Output over current protection |
|
| Yes |
|
|
General Data |
|
|
|
|
|
Dimensions(W/L/H)in mm |
|
| 329/403/240 |
|
|
Weight |
|
| 16kg |
|
|
Noise |
|
| <25dB |
|
|
Operation temperature range |
|
| -25℃~+60℃ |
|
|
Heat dissipation mode |
|
| Natural |
|
|
IP Class |
|
| IP 65 |
|
|
Maximum altitude |
|
| 4000m |
|
|
Self-Consumption night |
|
| <3w |
|
|
Topology |
|
| Transformerless |
|
|
Features |
|
|
|
|
|
LCD display |
|
| Yes |
|
|
Communication interface |
|
| WiFi/4G/USB/CAN/RS485 |
|
|
Standards |
|
| EN 62109-1/EN 62109-2/EN 62477-1/IEC 61000-6-1/IEC 61000-6-3/CEI 0-21/ UNE 217001/UNE 217002/VDE 0126/IEC 61727/IEC 62116/EN 50549-1/G98/ G99/AS 4777.2 |
|
|
